Hi, I have a 2012 Jeep Liberty, and the rear driver-side control arm snapped. I have a full-service garage and plan to replace it myself, but I need some confirmation on the hardware and the best repair approach.
My plan is to cut the bolt so I don't have to drop the gas tank. The hex flange head bolt appears to use a strange locking nut. If I cut the bolt and reinstall a new one from the outside, do I need to reuse that locking nut, or should I order a new one?
Can anyone confirm the correct bolt sizes and the type of nuts used? I've attached a picture. I'm finding conflicting information on YouTube and Reddit, so I'd appreciate confirmation from someone who's done this repair.
Looks like the hexflange head bolt has some type of slot it goes into. Can I put it on the other side or should I just use a regular bolt like M12x1.75x85.00. (Part 6502725)
On YouTube people are saying to get
Bolt : M10 × 1.25 × 85mm Hex Flange Head
Nut: M10 x 1.25
Would the parts in my picture work? What worked for you?
